VMR-C530N/W
페이지 정보
작성자 voda 댓글댓글 0건 조회조회 48회 작성일작성일 25-08-27 11:13본문
Main Features of the Camera
- 1/2.8-inch 5.69MP Sony Exmor CMOS Sensor
- 5MP 2560 × 1920 High Resolution / 30FPS
- H.265 / H.264 / MJPEG Triple Streaming
- White LEDs + 4 Infrared (IR) LEDs
-LDC / WDR / Fog Compensation / Flip Horizontal / Flip Vertical / Bidirectional (Horizontal, Vertical)
-PoE(IEEE802.3af)
- 2.8–12mm Motorized Lens
Data Sheet
Image Sensor
1/2.8 CMOS
Effective Pixels
2616(H) x 1964(V) 5MP
Lens Type
Auto 5.0mm~50mm / 2.8mm ~ 12mm
Illumination
Dual-light (LED+IR)
Day/Night Mode
Auto-light, starlight, searchlight, infrared mode
Shutter
Rolling
Shutter Speed
Auto(1/30~1/30000)
FPS
30fps
PLC Integration
Mitsubishi, Siemens (pre/post-event recording on PLC alarm)
Camera Position Detection
Automatic alarm for camera misalignment based on preset angle
Video Compression Format
H.264 MP / H.265 HP / MJPEG
Protocol
TCP/IP, HTTP, RTP, RTSP, UDP, DHCP, FTP, SMTP, NTP, ICMP
SDK Support
API, Onvif Profile S Compliant
Operating Temperature/Humidity
-10 ℃~+50 ℃/ 90%/ RH max
Basic Detection
Motion detection, ultra motion detection, tamper alarm, line crossing, intrusion detection
Power Supply
DC 12V, PoE (IEEE 802.3af)
Certifications
CE-EMC, CE LVD, CE-RoHS, FCC, CB, UL/CUL
Protection
IP67 (waterproof & dustproof)
Dimensions (W×H)
101mm / 82mm
File
- VMR-C530N.pdf (598.5K) 1 Download | DATE : 2025-09-22 16:14:21
- VMR-C530W.pdf (595.8K) 0 Download | DATE : 2025-09-22 16:14:21
