Axiomtek SHB160 /5B18-0GA1

작성자 voda 댓글댓글 0건 조회조회 43회 작성일작성일 25-08-27 15:10

※ feature

고객 특성에 맞춘 설계/ 고성능 다양한 종류의 포트 지원

[이 게시물은 voda님에 의해 2025-08-27 15:26:35 VARAVIEW에서 복사 됨]

Data Sheet

TYPE

VARASYS Backplane PC

CPU

INTEL CORE 14ᵗʰ /12ᵗʰ

Number Of Cores

I7-14700(2.1GHz/33MB) P8, E12 / I5-14500(2.6GHz/24MB) P6, E8 / I7-12700(2.1GHz/25MB) P8, E4 / I5-12500(3.0GHz/18MB) P6, E0

Power Supply

700~750W(Bronz), 800~1000W(Gold Modular) 80PLUS Power Supply

Operating System

Windows 10 IoT or Windows 11 IoT Enterprise LTSC

RAID Kit

RAIDON IR 2022 RAID 1 (Mirroring)

Industrial CPU-Board

PICMG 1.3 Full-Size CPU Card SHB160

CPU Card Slot

1 Slot

Slot

PCIe x16 1개 / PCI (32/33) 16개

Storage

SAMSUNG 870EVO 500GB x 2EA (RAID)

Size

Size(CASE)

GH-414SR 177(H) x 483(W) x 510(D)mm

Size(M/B)

18-slot BP for 20-slot chassis

Memory

R680E

4 x DDR5 ECC 2) or non-ECC Up to 192GB

H610E

2 x DDR5 Non-ECC Up to 64GB

RearI/O

USB /ETC

USB 3.2 Gen2 2개

Ethernet

2.5Gbps 2개

COM/GPIO

Display

DP 1개, DVI-I(colay VGA by project) 1개
